Water resistant putty powder packaging machine
Category : Putty powder production line
Release Date : 2025-03-25
View : 203times
Our automatic bagging packaging equipment has a high degree of automation, the equipment sets electronic weighing, automatic bagging, dust removal in one, is a multi-functional automatic bagging packaging equipment, its packaging accuracy can be controlled within 200g, packaging speed in the range of 180~220 bags/hour.
耗气量(m³/h)
Airconsumption(m³/h
|
30
|
除尘风量(m³/h)
Dustremovalair volume(m²/h
|
2000
|
尺 寸 ( m m )
Size(mm)
|
2118(1850)x1030x720
|
包装精度
Packaging accuragy
|
≤1%(25kg)
|
袋 重 范 围 ( k g )
Bagweight range(kg)
|
10-50
|
防护等级
Class of protection
|
≥IP54
|
适 用 袋 子 尺 寸 ( m m )
Applicable bag size(mm)
|
320-600
|
套袋速率(包/时)
Baggingrate (bag/hour)
|
180-400
|
封口方式
Sealing method
|
无/超声波
None/Ultrasonic
|
适用包装材质
|
纸袋、PE和PP阀口和复合阀口袋
|
功率(W)
Power (W)
|
550+2600
|
电 压 ( V )
Voltage(V)
|
380
|
气压(0 . 6Mpa)
Air pressure(0.6Mpa)
|
>=0.6
|
额定电流:
|
2A
|
重量
|
550kg
|
1. The weighing system is an electronic scale type measurement, using a comprehensive board digital adjustment and parameter setting, with weight cumulative display and automatic peeling, automatic zero correction, automatic drop correction and other functions, high sensitivity, strong anti-interference ability.
2. The instrument is equipped with a communication interface, which is convenient for online networking, and can carry out real-time monitoring and network management of the packaging machine.
3. With manual clearance function.
4. Air float plate quick disassembly design, easy to clean
5. Different sizes of pressure silos can be selected according to the density of materials.
Perfect after-sales service system
The company relies on a strong R & D design team, mature design concept, according to the customer's product formula and investment plan, optimize the process flow, tailor-made, to provide customers with economic product solutions.
From investment analysis, market refinement, equipment selection, after-sales installation, personnel training, maintenance, formula support one-stop thoughtful and meticulous service, global quality parts procurement makes your equipment stable operation.
In the face of increasingly strict background, the company optimizes the process flow, the comprehensive treatment of dust removal and emission, so that the equipment can be, energy saving and operation. Service engineers, always keep an eye on your equipment. Ensure the stable and reliable operation of your equipment to effectively reduce equipment maintenance costs.
